YOTB-48B Optical Terminal Box
Overview
YOTB-48B Metal OTB, also known as Fiber Optic FTTH Double Door Terminal Box, is made of cold-rolled steel. Used as a termination point for the feeder cable to connect with the drop cable in the FTTX communication network system. Fiber splicing, splitting and distribution can be done in this box, and at the same time, it provides solid protection and management for the FTTX network building.
Specifications
| Items | Parameter |
| Maximum Fiber Capacity | 48 Ports |
| Mounting Type | Wall mounting |
| Shell Material | Cold rolled steel |
| Door | 2 doors at front |
| Inlet / Outlet Ports Number | 4 PCS/4 PCS |
| Outside Dimension (H*W*D) | 380*325.5*92mm |
| Working Environment | Outdoor & indoor |
| Working Temperature | -45~+65℃ |
| Relative Humidity | ≤95%(At 40℃) |
| Air Pressure | 80~106Kpa |
| Color | Gray Default RAL 7035 |
Configuration
| Items | Parameter |
| Splice Sleeve | 72 PCS |
| Worm Gear Pipe Clamp | φ9-16mm*8 PCS |
| Plastic Cable Tie(L*W) | 100*3mm*10 PCS |
| Fiber Protection Tube | 6m |
| Expansion bolt | 4 PCS |
| Adapter | FC/SC/LC |
| Pigtail | Optional |
Applications
· Wall mounting
· FTTH pre-installation and filed installation
· Telecommunication network
· Data communications network
· Local area networks
