Overview
YFSC-T48A Fiber Splice Closure, also known as Fiber Optical Splice closure, is a 2 inlet port, 2 outlet port mechanically sealed Horizontal Type Fiber Optical Splice closure, suitable for overhead and buried cable via split connection, comes with 2 splice trays with a maximum capacity of 24 cores for different cable configurations in any environment (pipeline, overhead, underground and manhole), as well as many connection applications such as mid-span, branch and direct connections. This product is an open type high quality engineering plastic box body and can be opened again after sealing, and can be reused.
Specifications
Items | Parameter |
Maximum Fiber Capacity | 96 Ports |
Mounting Type | Aerial-mounted Duct-mounted Underground |
Material | PC |
Seal Material | Self-adhesive rubber |
Protection Class | IP68 |
Fiber Cable Diameter | Φ10~22mm |
Inlet / Outlet Ports Number | 2 PCS/2 PCS |
Weight | 2.3kg |
Dimension | 460*175*115mm |
Working Temperature | -40℃~65℃ |
Relative Humidity | ≤85%(At 30℃) |
Color | Black |
Packing Dimension | 6PCS/CTN, 495*395*415mm |
Packing Weight | 14kg |
Configuration
Items | Parameter |
Splice Sleeve | 96 PCS |
Splice Tray | ≤4 PCS |
Maximum Core Of The Splice Tray | 24 Cores |
