Overview
YOTB-2A Optical Terminal Box, also known as OTB, is used as a termination point for the feeder cable to connect with the drop cable in the FTTX communication network system. Fiber splicing, splitting and distribution can be done in this box, and at the same time, it provides solid protection and management for the FTTX network building.
Specifications
| Items | Parameter |
| Maximum Fiber Capacity | 2 Ports |
| Mounting Type | Wall mounting Pole mounting |
| Shell Material | ABS |
| Door | 1 door at front |
| Inlet / Outlet Ports Number | 1 PCS/1 PCS |
| Outside Dimension (H*W*D) | 86*86*25mm |
| Working Environment | Outdoor & indoor |
| Working Temperature | -45~+65℃ |
| 相对湿度 Relative Humidity | ≤95%(At 40℃) |
| Air Pressure | 80~106Kpa |
| Color | White |
Configuration
| Items | Parameter |
| Splice Sleeve | 1 PCS |
| Screw | 2 PCS |
| Plastic Parts | 1 PCS |
| Adapter | SC |
| Pigtail | Optional |
Applications
· Wall mounting and pole mounting installtion
· FTTH pre-installation and filed installation
· 5-10mm cable ports suitable for 2x3mm indoor FTTH drop cable and outdoor figure 8 FTTH self-supporting drop cable
